Products
Features
-
High
Precision
-
Exceptional
Compatibility
-
Long
Life
-
No Maintenance
Performance Parameters
Precise, rapid switching.
Outstanding wear and corrosion resistance.
Communication via RS-232、RS-485、IIC, or CAN.
Equipped with 1/4-28UNF or 6-40UNF.
Compatible power supply: 24VDC.
Product Selection
| P/N | Configuration | Bore Diameter | Internal Volume | Thread | Max Pressure | Wetted Material |
|---|---|---|---|---|---|---|
| SVC-L8-24-A | 24 Position-25 Port | Φ0.5mm | 3.3μL | 6-40UNF | 5000Kpa | FFKM, PEEK, PVDF, Ceramic |
| SVC-L8-16-A | 16 Position-17 Port | Φ0.76mm | 16.85μL | 1/4-28UNF | 5000Kpa | FFKM, PEEK, PVDF, Ceramic |
| SVC-L8-12-A | 12 Position-13 Port | Φ1.0mm | 15.60μL | 1/4-28UNF | 5000Kpa | FFKM, PEEK, PVDF, Ceramic |
| SVC-L8-10-A | 10 Position-11 Port | Φ1.5mm | 33.19μL | 1/4-28UNF | 5000Kpa | FFKM, PEEK, PVDF, Ceramic |
| SVC-L8-8-A | 8 Position-9 Port | Φ1.5mm | 31.64μL | 1/4-28UNF | 5000Kpa | FFKM, PEEK, PVDF, Ceramic |
| SVC-L8-6-A | 6 Position-7 Port | Φ1.5mm | 32.83μL | 1/4-28UNF | 5000Kpa | FFKM, PEEK, PVDF, Ceramic |
P/N: SVC-L8-24-A: SVC: Ceramic Rotary Valve, L: Low-Pressure, 8: Series 8, 24: 24 Position-25 Port, A: Sequence Code
